Kenda Karrier KR03 Radial Trailer Tire LRD 8ply ST175/80R13

KendaSKU: TIR100212
No reviews
Price:
$78.91

WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Description

The Karrier KR03 is an ST radial trailer tire with dual steel belts and full nylon ply reinforcement. Its four-rib all-season tread has a center rib for straight tracking and even traction, and the grooves are shaped to eject stones and road debris. It is built for boat, camper and cargo trailers, including long-distance highway towing.

Tire Specifications

Tire size
ST175/80R13Decode this size
Overall diameter
24.1 in
Section width
7 in
Ply rating
8
Size & fitment
Tire sizeST175/80R13
Rim diameter13 in
Approved rim widths5 in
PositionAll Positions
Vehicle applicationTrailer
Construction
ConstructionRadial
Ply rating8
Load rangeD
Dimensions
Overall diameter (actual)24.1 in
Section width (actual)7 in
Tread depth (new)9/32"
Load & speed
Load index98
Max load per tire (single)1,650 lb
Cold pressure at max load70 PSI
Speed ratingM
What's included
Package contentsTire only
Tires included1
General
BrandKenda
MPN09R031331D1
SKUTIR100212
Shipping weight20.16 lb

Specifications are the manufacturer's published values. Actual dimensions vary with rim width, inflation pressure and load.

Mounted dimensions

7 in section width 24.1 in overall diameter 13 in rim diameter 5 in rim width
Drawn to scale from the manufacturer's published dimensions on the approved rim at the rated pressure. Actual dimensions vary with rim width, inflation pressure and load.
At a glance
Tire sizeST175/80R13
Overall diameter24.1 in
Section width7 in
Rim diameter13 in
Approved rim width5 in
Tread depth (new)9/32"
Fitment GuideWhat Does ST175/80R13 Mean?See what every part of this size tells you, from the width and wheel size to the load and speed rating.Decode This Size

The Karrier KR03 is an ST radial trailer tire with dual steel belts and full nylon ply reinforcement. Its four-rib all-season tread has a center rib for straight tracking and even traction, and the grooves are shaped to eject stones and road debris. It is built for boat, camper and cargo trailers, including long-distance highway towing.

Features

  • 1 Radial Trailer Tire
  • Advanced Rubber Compound. 8 ply rated in Load Range D, carrying up to 1650 lbs at 70 PSI (load index 98).
  • Heavy duty nylon plies for increased tire life. Measures 24.1 in mounted diameter, 7 in mounted width, a 5 in rim.
  • Smooth ride with additional stability. 9/32 in tread depth.
  • M speed rated, good for 81 mph. Built for trailer service only and not for use on a light truck. Sold as a tire only, wheel not included.
