4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel
4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel
4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel
4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel
Roll over image to zoom in Click on image to zoom
4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel

4.80-8 LRC 6 Ply Deestone D901 Trailer Tire on a 4 on 4 Steel Wheel

DeestoneSKU: TWA19010/7500X
No reviews
Price:
$52.65

Description

Featuring a Deestone D901 trailer tire and a Premium Service white with red and blue pinstripes modular steel wheel this tire and wheel assembly will save you time from having to mount the tire to the wheel as it is ready to install. The Deestone D901 trailer tire features a 5 rib 4 groove tread design which offers excellent handling and stability.

Tire Specs

  • Model: D901
  • MPN: DS7251
  • Tire Size: 4.80-8
  • Load Range: C
  • # of Ply's: 6
  • Speed Rating: J
  • Mtd. Diameter (Inches): 16.7
  • Mtd. Width (Inches): 4.6
  • Rim Width (Inches): 3.75
  • Max Load (lbs): 760
  • Max PSI: 90
  • Tread Depth (32nds): 7
  • Tire Weight (lbs): 5.963
  • Tire Quantity: 1

Wheel Specs

  • Size: 8x3.75
  • Bolt Pattern: 4x4
  • Center Hole (Inches): 2.81
  • Offset (Inches): 0
  • Backside Spacing (Inches): 2.38
  • Load Capacity (lb): 900
Tire and Wheel AssemblySolid Steel Wheel4 LugReady to InstallWhiteTire and Wheel AssemblySolid Steel Wheel4 LugReady to InstallWhite

Features

  • Tire and Wheel Assembly
  • Solid Steel Wheel
  • 4 Lug
  • Ready to Install
  • White

Tire Specifications

Tire size
4.80-8Decode this size
Overall diameter
16.7 in
Section width
4.6 in
Ply rating
6
Size & fitment
Tire size4.80-8
Rim diameter8 in
Approved rim widths3.75 in
Vehicle applicationTrailer
Construction
ConstructionBias
Ply rating6
Load rangeC
Dimensions
Overall diameter (actual)16.7 in
Section width (actual)4.6 in
Tread depth (new)7/32"
Load & speed
Load index71
Max load per tire (single)760 lb
Cold pressure at max load90 PSI
Speed ratingJ
What's included
Package contentsMounted tire and wheel
Tires included1
General
BrandDeestone
MPN19010 | 7500X
SKUTWA19010/7500X
Shipping weight10.14 lb

Wheel & Hub Specifications

Size & fitment
Rim width3.75 in
Bolt pattern4 on 4
Center hole2.81 in
Offset0 in
Backside spacing2.38 in
Load & application
Load capacity900 lb

Specifications are the manufacturer's published values. Actual dimensions vary with rim width, inflation pressure and load.

Mounted dimensions

4.6 in section width 16.7 in overall diameter 8 in rim diameter 3.75 in rim width
Drawn to scale from the manufacturer's published dimensions on the approved rim at the rated pressure. Actual dimensions vary with rim width, inflation pressure and load.
At a glance
Tire size4.80-8
Overall diameter16.7 in
Section width4.6 in
Rim diameter8 in
Approved rim width3.75 in
Tread depth (new)7/32"
Fitment GuideWhat Does 4.80-8 Mean?See what every part of this size tells you, from the width and wheel size to the load and speed rating.Decode This Size

Wheel dimensions

CROSS-SECTION INBOARD vehicle side 3.75 in rim width 8 in rim diameter 2.38 in backspacing0 in offset, mounting face on the centerline FACE VIEW 4 on 4 in bolt pattern 2.81 in center hole
Drawn to scale from the published wheel specifications. Backspacing runs from the hub mounting face to the inboard edge of the rim; a positive offset puts the mounting face outboard of the wheel centerline.
At a glance
Wheel size8 x 3.75 in
Bolt pattern4 on 4 in
Center hole2.81 in
Backspacing2.38 in
Offset0 in
Load capacity900 lb
Fitment GuideNot Sure It Fits?Measure your own wheel in 7 steps, with an animated drawing for each one.Open the Guide

Featuring a Deestone D901 trailer tire and a Premium Service white with red and blue pinstripes modular steel wheel this tire and wheel assembly will save you time from having to mount the tire to the wheel as it is ready to install. The Deestone D901 trailer tire features a 5 rib 4 groove tread design which offers excellent handling and stability.

Tire Specs

  • Model: D901
  • MPN: DS7251
  • Tire Size: 4.80-8
  • Load Range: C
  • # of Ply's: 6
  • Speed Rating: J
  • Mtd. Diameter (Inches): 16.7
  • Mtd. Width (Inches): 4.6
  • Rim Width (Inches): 3.75
  • Max Load (lbs): 760
  • Max PSI: 90
  • Tread Depth (32nds): 7
  • Tire Weight (lbs): 5.963
  • Tire Quantity: 1

Wheel Specs

  • Size: 8x3.75
  • Bolt Pattern: 4x4
  • Center Hole (Inches): 2.81
  • Offset (Inches): 0
  • Backside Spacing (Inches): 2.38
  • Load Capacity (lb): 900
Tire and Wheel AssemblySolid Steel Wheel4 LugReady to InstallWhiteTire and Wheel AssemblySolid Steel Wheel4 LugReady to InstallWhite

Features

  • Tire and Wheel Assembly
  • Solid Steel Wheel
  • 4 Lug
  • Ready to Install
  • White
