Description
The HD Field Trax is an all-around field, farm and outdoor favorite. Its wide profile keeps the machine stable on hard-packed surfaces, and the non-directional tread gives a smooth ride while resisting cuts, chips and abrasion.
- Tire size26x12.00-12
- Rim12 in
- Rim width9.5 in
- Load rangeA (2 ply)
- Max load760 lb @ 10 PSI
- TypeTubeless, bias
Quantity
Carlisle HD Field Trax ATV UTV Tire 2ply 26x12-12 NHS TL
$203.85
Documents
Tire Specifications
- Tire size
- 26x12.00-12Decode this size
- Overall diameter
- 25.4 in
- Section width
- 12.2 in
- Ply rating
- 2
| Tire size | 26x12.00-12 |
|---|---|
| Rim diameter | 12 in |
| Approved rim widths | 9.5 in |
| Position | All Positions |
| Vehicle application | ATV/UTV |
| Terrain | Hard pack, field and turf |
| Construction | Bias |
|---|---|
| Ply rating | 2 |
| Load range | A |
| Tube requirement | Tubeless |
| Overall diameter (actual) | 25.4 in |
|---|---|
| Section width (actual) | 12.2 in |
| Tread depth (new) | 20/32" |
| Load index | 71 |
|---|---|
| Max load per tire (single) | 760 lb |
| Cold pressure at max load | 10 PSI |
| Speed rating | NHS: Not for Highway Service |
| Package contents | Tire only |
|---|---|
| Tires included | 1 |
| Brand | Carlisle |
|---|---|
| MPN | 560467 |
| SKU | TIR18102 |
| Shipping weight | 25.2 lb |
Specifications for this option are not available yet.
Specifications are the manufacturer's published values. Actual dimensions vary with rim width, inflation pressure and load.
Mounted dimensions
| Tire size | 26x12.00-12 |
|---|---|
| Overall diameter | 25.4 in |
| Section width | 12.2 in |
| Rim diameter | 12 in |
| Approved rim width | 9.5 in |
| Tread depth (new) | 20/32" |
Dimensions for this option are not available yet.
The HD Field Trax is an all-around field, farm and outdoor favorite. Its wide profile keeps the machine stable on hard-packed surfaces, and the non-directional tread gives a smooth ride while resisting cuts, chips and abrasion.
