Carlisle 8x5.375 5 on 4.5 Steel Trailer Wheel - White -.75" Offset
Roll over image to zoom in Click on image to zoom
Carlisle 8x5.375 5 on 4.5 Steel Trailer Wheel - White -.75" Offset

Carlisle 8x5.375 5 on 4.5 Solid Trailer Wheel, -0.75" Offset - White

CarlisleSKU: WHL7532
No reviews
Price:
$118.33

WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Description

The Carlisle Highway Standard is a solid center steel trailer wheel for utility and specialty trailers. A continuous steel face runs from hub to rim, so there are no openings to pack with mud, sand or road debris.

This is the 8x5.375 size on a 5 on 4.5 (5x114.3 mm) bolt pattern, rated for 1,075 lbs per wheel. It has a 2.812 inch center bore, a -0.75 inch offset and 2.25 inches of backside spacing. The finish is white, and it takes 60 degree cone lug nuts.

Measure the bolt pattern on the hub itself: on a 5 lug hub, go from the center of one stud to the outside edge of the stud two positions over. A 5 on 4.75 hub is only a quarter inch larger, so take your time with the tape. Then match the center bore and backside spacing to the wheel you are replacing.

This listing includes 1 wheel. It ships boxed without a valve stem, and the tire is not included.

Wheel Specifications

Wheel size
8 x 5.375 in
Bolt pattern
5 on 4.5
Center hole
2.812 in
Load capacity
1,075 lb
Size & fitment
Rim diameter8 in
Rim width5.375 in
Bolt pattern5 on 4.5
Center hole2.812 in
Offset-0.75 in
Backside spacing2.25 in
Load & application
Load capacity1,075 lb
Vehicle applicationTrailer
General
BrandCarlisle
MPN0815295266B
SKUWHL7532
Shipping weight5.65 lb

Specifications are the manufacturer's published values.

Wheel dimensions

CROSS-SECTION INBOARD vehicle side 5.375 in rim width 8 in rim diameter 2.25 in backspacing -0.75 in offset, toward inboard FACE VIEW 5 on 4.5 in bolt pattern 2.812 in center hole
Drawn to scale from the published wheel specifications. Backspacing runs from the hub mounting face to the inboard edge of the rim; a positive offset puts the mounting face outboard of the wheel centerline.
At a glance
Wheel size8 x 5.375 in
Bolt pattern5 on 4.5 in
Center hole2.812 in
Backspacing2.25 in
Offset-0.75 in
Load capacity1,075 lb
Fitment GuideNot Sure It Fits?Measure your own wheel in 7 steps, with an animated drawing for each one.Open the Guide

The Carlisle Highway Standard is a solid center steel trailer wheel for utility and specialty trailers. A continuous steel face runs from hub to rim, so there are no openings to pack with mud, sand or road debris.

This is the 8x5.375 size on a 5 on 4.5 (5x114.3 mm) bolt pattern, rated for 1,075 lbs per wheel. It has a 2.812 inch center bore, a -0.75 inch offset and 2.25 inches of backside spacing. The finish is white, and it takes 60 degree cone lug nuts.

Measure the bolt pattern on the hub itself: on a 5 lug hub, go from the center of one stud to the outside edge of the stud two positions over. A 5 on 4.75 hub is only a quarter inch larger, so take your time with the tape. Then match the center bore and backside spacing to the wheel you are replacing.

This listing includes 1 wheel. It ships boxed without a valve stem, and the tire is not included.

Features

  • Puts a solid center steel wheel under your utility or specialty trailer, with no openings to pack with mud or debris.
  • Measures 8 x 5.375 inches on a 5 on 4.5 inch (5x114.3 mm) bolt pattern, rated to carry 1,075 lbs per wheel.
  • Fits 5 lug trailer hubs with a 5 on 4.5 bolt pattern: 2.812 inch center bore, a -0.75 inch offset and 2.25 inch backside spacing. Takes 60 degree cone lug nuts.
  • Steel solid center construction from the Carlisle Highway Standard line, finished in white.
  • Sold individually, tire not included, and it ships boxed without a valve stem. Match the bolt pattern, center bore and backside spacing to your hub before ordering.
