Schrader 53736 HD 433 MHz TPMS Sensor for Kenworth & Peterbilt, Q21-1171
Pasa el cursor sobre la imagen para ampliarla. Clic en la imagen para aumentar
Schrader 53736 HD 433 MHz TPMS Sensor for Kenworth & Peterbilt, Q21-1171

Schrader 53736 HD 433 MHz TPMS Sensor for Kenworth & Peterbilt, Q21-1171

SchraderSKU: TPM53736
0 reseña
Precio:
$54.93

WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Descripción

The Schrader 53736 is a 433 MHz heavy duty OE replacement sensor for select 2025 and newer Kenworth and Peterbilt trucks. It replaces OE sensor Q21-1171 and works with the factory TPMS.

It supports the factory system features Schrader lists, including Auto Learn, Auto Location, Tire Burst Warning, Tire Lock Warning and Tire Fill Assist. It mounts on a Schrader HD valve kit sold separately: 57001 (steel rim, 56 mm straight), 57005 (alloy rim, 40 mm straight), 57009 (TR554D, 60 degree), 57011 (27 degree), 57012 (TR546, 4.25 in straight) or 57010. Torque the sensor screw to 4 Nm (about 35 in-lb).

This listing includes one sensor body; the valve kit is sold separately.

TPMS Sensor Specifications

Frequency
433 MHz
Sensor type
Direct fit (vehicle specific)
Valve stem
Not included
Pack quantity
1
Sensor
Frequency433 MHz
Sensor typeDirect fit (vehicle specific)
Valve stemNot included
Pack quantity1
Fitment & programming
Vehicle makesKenworth, Peterbilt
Vehicle applicationTruck
Cross reference
Interchange part numbersQ21-1171
General
BrandSchrader
MPN53736
SKUTPM53736
Shipping weight0.25 lb

Specifications are from the manufacturer's published data where available. Check your rim's valve hole size and your TPMS sensor before ordering.

The Schrader 53736 is a 433 MHz heavy duty OE replacement sensor for select 2025 and newer Kenworth and Peterbilt trucks. It replaces OE sensor Q21-1171 and works with the factory TPMS.

It supports the factory system features Schrader lists, including Auto Learn, Auto Location, Tire Burst Warning, Tire Lock Warning and Tire Fill Assist. It mounts on a Schrader HD valve kit sold separately: 57001 (steel rim, 56 mm straight), 57005 (alloy rim, 40 mm straight), 57009 (TR554D, 60 degree), 57011 (27 degree), 57012 (TR546, 4.25 in straight) or 57010. Torque the sensor screw to 4 Nm (about 35 in-lb).

This listing includes one sensor body; the valve kit is sold separately.

Features

  • Replaces the factory 433 MHz TPMS sensor on select Kenworth and Peterbilt trucks (OE Q21-1171).
  • 433 MHz heavy duty OE replacement sensor with Auto Learn, Auto Location, Tire Burst and Tire Fill Assist support.
  • Fits 2025 and newer Kenworth T180, T280, T380, T480, T680, T880 and W990, and Peterbilt 520, 535, 536, 537, 548, 567 and 589.
  • Valve-mounted 35 g sensor body that fits Schrader HD valve kits 57001, 57005, 57009, 57010, 57011 and 57012; screw torque 4 Nm.
  • Includes one sensor body only; order a Schrader HD valve kit to match the wheel and valve hole.
